Parent Layer:
Natural Hazards
Name: Channel Migration Areas
Display Field: Shape.STArea()
Type: Feature Layer
Geometry Type: esriGeometryPolygon
Description: Conventional flood hazard maps, like the FEMA Flood Insurance Rate Map (FIRM) series, examine only the hazard posed by standing floodwaters on a given floodplain. Damage from bank erosion as river channels naturally migrate may be far greater locally and may occur even in the absence of major flooding. To address this hazard, channel migration hazard maps were created to identify areas susceptible to future channel movement and erosion. Following the methodology of Rapp and Abbe (2003) and Abbe and others (2008), lidar-derived digital elevations models and serial aerial photography were examined to map the position of the channel over time. Localized erosion rates, potential avulsion sites, areas where erosion may be prevented, and areas where infrastructure is at risk from erosion were identified from these data. The resulting Channel Migration Zone and its subzones represent best estimates of the likely hazard projected 100 years into the future. The analysis area is mostly within the geologic floodplain of the river, with some exceptions where forecasted erosion boundaries intersect active landslides. In these locations, the Channel Migration Zone may include the landslide toe. The channel hazard maps should be used as a guide for local governments, land owners, and infrastructure managers to identify assets potentially at risk and to develop effective mitigation measures. For more information on methodologies, see DOGAMI OFR O-11-09, Channel Migration Hazard Maps, Coos County, Oregon.
Copyright Text: John T. English, Daniel E. Coe, and Robert D. Chappell
Default Visibility: true
MaxRecordCount: 2000
Supported Query Formats: JSON, geoJSON, PBF
Min Scale: 0
Max Scale: 0
Supports Advanced Queries: true
Supports Statistics: true
Has Labels: false
Can Modify Layer: true
Can Scale Symbols: false
Use Standardized Queries: true
Supports Datum Transformation: true
Extent:
XMin: 7713940.4501312375
YMin: 659244.6873359531
XMax: 7750342.941272959
YMax: 698600.4455380589
Spatial Reference: 2913
(2913)
Drawing Info:
Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 20
Labeling Info:
Advanced Query Capabilities:
Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
HasZ: false
HasM: false
Has Attachments: false
HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText
Type ID Field: null
Fields:
-
OBJECTID
(
type: esriFieldTypeOID, alias: OBJECTID
)
-
Shape
(
type: esriFieldTypeGeometry, alias: Shape
)
-
Shape.STArea()
(
type: esriFieldTypeDouble, alias: Shape.STArea()
)
-
Shape.STLength()
(
type: esriFieldTypeDouble, alias: Shape.STLength()
)
Supported Operations:
Query
Generate Renderer
Return Updates
Iteminfo
Thumbnail
Metadata
