Parent Layer: Transportation Layers

Name: Culverts

Display Field: NamedBody

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This feature class contains Multnomah County stormwater culvert infrastructure. A variety of methods and data sources were employed to create this data. Existing datasets obtained from neighbor jurisdictions were used as a starting point. Point accuracy (within the county right of way) was then improved using the best available data sources. These sources include resource grade GPS, Ground Based LIDAR, Aerial Photos, Georeferenced As-Built Drawings, Georeferenced Mylar Drawings, Field Visits, and Google Streetview. Depending on the source used to verify the data, the accuracy of this feature class is estimated to be &lt; 3 meters</SPAN></P><P><SPAN /></P><P><SPAN /></P></DIV></DIV></DIV>

Copyright Text: Multnomah County DCS - Business Services

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 50000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 7580880.321850389
YMin: 651255.1115485579
XMax: 7796788.954724416
YMax: 758145.0544619411
Spatial Reference: 2913  (2913)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 92, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CVID ( type: esriFieldTypeInteger, alias: CVID )
• Diameter ( type: esriFieldTypeDouble, alias: Diameter )
• ShapeType ( type: esriFieldTypeString, alias: Shape, length: 50 , Coded Values: [Arch: Arch] , [Circular: Circular] , [Ellipse: Ellipse] , ...2 more... )
• Material ( type: esriFieldTypeString, alias: Material, length: 50 , Coded Values: [ABS: ABS] , [ADS: ADS] , [Bell Concrete: Bell Concrete] , ...17 more... )
• Length ( type: esriFieldTypeDouble, alias: Length )
• Slope ( type: esriFieldTypeDouble, alias: Slope )
• CarriedType ( type: esriFieldTypeString, alias: CarriedType, length: 50 , Coded Values: [Ditch: Ditch] , [Stormwater runoff: Stormwater runoff] , [Stream: Stream] )
• NumberCulverts ( type: esriFieldTypeSmallInteger, alias: NumberCulverts )
• InletType ( type: esriFieldTypeString, alias: InletType, length: 50 , Coded Values: [Catch Basin: Catch Basin] , [Inlet Grate: Inlet Grate] , [Open: Open] , ...6 more... )
• Owner ( type: esriFieldTypeString, alias: Owner, length: 50 , Coded Values: [Fairview: City of Fairview] , [Gresham: City of Gresham] , [Lake Oswego: Lake Oswego] , ...7 more... )
• DateInstall ( type: esriFieldTypeDate, alias: Date_Install, length: 8 )
• NamedBody ( type: esriFieldTypeString, alias: Named_Body, length: 50 )
• Fish ( type: esriFieldTypeString, alias: Fish, length: 50 )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 250 )
• ImageLink ( type: esriFieldTypeString, alias: Image_Link, length: 250 )
• ImageLink2 ( type: esriFieldTypeString, alias: Image_Link_2, length: 250 )
• OutletType ( type: esriFieldTypeString, alias: OutletType, length: 50 , Coded Values: [Catch Basin: Catch Basin] , [Inlet Grate: Inlet Grate] , [Open: Open] , ...6 more... )
• Orientation ( type: esriFieldTypeString, alias: Orientation, length: 50 , Coded Values: [Cross Culvert: Cross Culvert] , [Driveway Encroachment Culvert: Driveway/Encroachment Culvert] , [Other: Other] , ...1 more... )
• GrandTotal ( type: esriFieldTypeDouble, alias: GrandTotal )
• Enabled ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Generate Renderer   Return Updates
